LED Theatre spot with 100 W UV COB LED
- 1 powerful LED 100 W COB (chip-on-board) ultra violet (UV)
- UV effect
- The device is cooled by cooling fan
- Control via stand-alone; DMX; Sound to light via Microphone; Master/slave function; CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional)
- Flicker-free
- With a beam angle of 40°
- 4 digit 7-segment LED display
- Dimmer electronic
- Preprogrammed in Light´J; Light Captain
- Mains input and output for power linking up to 8 units
- With bracket for floor use
Package contents
- 1 x spotlight, 1 x power cord, 1 x user manual
Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
85 W
IP classification:
IP20
Protection class:
Protection class I
Power connection:
Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:
P-Con (gray), mounting version
Fuse:
5 x 20 mm, T 1 A Fuse replaceable
Lamp type:
LED lamp
LED:
1 x 100 W COB (chip-on-board) ultra violet (UV)
Flash rate:
0 - 20 Hz
DMX channels:
1; 4
DMX input:
3-pin XLR (M) mounting version
DMX output:
3-pin XLR (F) mounting version
Cooling:
Cooling fan
Control:
Stand-alone; DMX; Sound to light via Microphone; Master/slave function; CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional)
Preprogrammed in:
Light´J; Light Captain
Beam angle:
40°
Beam angle (1/2 peak):
40°
Beam angle (1/10 peak):
70°
Illuminance in Lux (lx):
Ultra violet (UV) 1m: 38 lx, 3m: 6 lx, 6m: 2 lx
Wavelength:
Ultra violet (UV) 402 nm
Housing color:
Black
Attachment system:
Bracket for floor use
Display type:
4 digit 7-segment LED display
Dimensions:
Width: 24,3 cm
Depth: 31,1 cm
Height: 32,0 cm
Weight:
2,75 kg
Photobiological safety:
Risk Group 0
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
