- For application areas such as: Mobile use
OMNITRONIC MAXX-1206 2-Way Top 6.5" 2x white
2 x 6.5" passive full-range speaker, 100 W RMS
- 2-way bass-reflex system with 6.5" bass-midrange speaker and 1" titanium compression driver
- Serve as a mobile 2.1 system together with the MAXX-1206 subwoofer
- With passive 2-way crossover, PTC tweeter protection
- White metal grille with acoustic foam
- Rugged carrying handle
- 2 pieces per set
- Application possibility: Standing; suspended; monitoring; on tripod
- With rigging points
Package contents
- 2 x top, 2 x speaker cable
OMNITRONIC MAXX-1206DSP 2.1 Active Subwoofer 12" white
High-power 12" active subwoofer with DSP and Bluetooth, 450 watts
- 12" subwoofer with Class D amplifier in bassreflex cabinet
- Amplifier power: 250 W RMS + 2 x 100 W RMS for two satellites
- Serves as a mobile 2.1 system together with MAXX-1206 2-way tops
- Balanced signal input XLR/6.3 mm jack L/R
- Additional stereo RCA input, with level switch
- Separate volume control for subwoofer and satellites
- Stereo/mono selection
- Digital signal processor
- Control via Bluetooth
- Rubber feet
- White metal grille with acoustic foam
- DSP presets: FLAT; DJ; LIVE
- Wheels optional
- Application possibility: Standing
Package contents
- 1 x bass, 1 x power cord, 1 x strap, 1 x user manual, 1 x declaration of conformity
Weight:
34,35 kg
OMNITRONIC MAXX-1206 2-Way Top 6.5" 2x white
Power:
Program: 200W
Rated: 100W RMS
Frequency range:
100 - 17000 Hz
Sensitivity:
91 dB
Max. SPL:
115 dB
Dispersion angle:
90° x 60°
Impedance:
4 ohms
Attachment system:
Flange: Ø 35mm
Flying points:
3 x M8 thread
Connections:
Input: speaker via 1 x speaker built-in socket (F)
Speaker:
1 x woofer (6.5") approx. 17 cm
Basket material: Steel
Conematerial: Cardboard/paper
1 x compression tweeter highs (1") approx. 2.5 cm
Type of speaker:
Compact cabinet speaker
Carrying handle:
1 pc/pcs
Material:
MDF (Medium-density fibreboard), 16 mm
Color:
White, textured coating, painted
Dimensions:
Width: 20,4 cm
Depth: 19 cm
Height: 36,2 cm
Weight:
12,70 kg
OMNITRONIC MAXX-1206DSP 2.1 Active Subwoofer 12" white
Power supply:
230 V AC, 50 Hz
Power consumption:
500 W
Protection class:
Protection class I
Power connection:
Mains input via IEC connector (M) mounting version power supply cord with safety plug included
Device fuse:
5 x 20 mm, T 4 A Fuse replaceable
Power:
Rated: 250W RMS LF
Rated: 2x 100W RMS HF
Frequency range:
38 - 250 Hz Bass
100 - 17000 Hz Top
Sensitivity:
97 dB
Max. SPL:
119 dB
DSP:
Digital signal processor
DSP presets:
FLAT; DJ; LIVE
Control:
Bluetooth
Bluetooth device name:
OMNITRONIC MAXX1206
Attachment system:
Flange: M20 thread
Circuitry:
Class D
Control elements:
Power switch, level control, Input sensitivity switch, connect, tone control
Controls:
Limiter
Status LED:
Power, signal, limit, pairing, DSP presets
Connections:
Input: line via 1 x stereo RCA
Input: line via 2 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version)
Output: line via 2 x 3-pin XLR (M) mounting version
Output: speaker via 2 x speaker built-in socket (F)
Input channels:
1 x stereo via XLR or RCA or bluetooth, channel control via Rotary dial
Speaker:
1 x woofer (12") approx. 30 cm with ferrit magnet
Basket material: Steel
Conematerial: Cardboard/paper
USB port:
1 x Typ C, 2 A
Type of speaker:
Subwoofer
Type of construction:
Vented
Transport aid:
Rubber feet
Wheels optional
Material:
MDF (Medium-density fibreboard), 16 mm
Color:
White, textured coating, painted
Dimensions:
Width: 38,4 cm
Depth: 47,4 cm
Height: 45,8 cm
Weight:
19,50 kg
